MH-PB
MINGHUNG
Production Line Features
Economical Investment: Uses batch multi-opening press instead of continuous press, reducing equipment cost by 40–60%
Flexible Raw Materials: Adapts to branches, small-diameter logs, sawdust, recycled furniture waste and other low-cost materials
Simplified Process: No complex surface refining or air-flow forming; mainly mechanical forming
Energy-Saving Design: Hot press waste heat returned for drying; power consumption ≤ 150 kWh/m³
User-Friendly Operation: PLC semi-automatic control with manual override capability; short training period
Easy Maintenance: Uses standard common components; easy local replacement
Fast Installation: Modular design; installation & commissioning only 3–5 months
Main Production Line Equipment (Economical Configuration)
Equipment Unit | Function Description | Economical Configuration Note |
Drum Chipper | Primary chipping of logs/waste | Single unit, capacity sufficient for line |
Hammer Mill | Fine crushing of sawdust/shavings | Optional (depending on raw material) |
Single-pass Dryer | Drying particles | Traditional rotary type, not high-efficiency |
Simple Screening Machine | Particle classification | Single or double deck vibrating screen |
Drum Blender | Gluing and mixing | Single-stage gluing, no surface/core separation |
Mechanical Forming Machine | Mat formation | Mechanical spreading, not air-flow type |
Multi-opening Hot Press (4–8 openings) | Hot pressing | Batch type, manual/semi-auto loading/unloading |
Simple Cooling Rack | Natural cooling | No forced air cooling |
Four-head Sander | Thickness sanding | Economical type, tolerance ±0.3 mm |
Manual Wrapping Line | Finished product packaging | Simple stretch or steel strapping |
Technical Parameters
Parameter | Range/Value |
Finished panel thickness | 6 – 25 mm |
Finished panel width | 1220 mm (fixed) or 1830 mm |
Finished panel length | 2440 mm (fixed) or customized |
Finished panel density | 600 – 700 kg/m³ |
Production capacity | 10,000 – 50,000 m³/year |
Hot press type | Multi-opening batch (4/6/8 openings) |
Hot press temperature | 160 – 200°C |
Hot press pressure | 2.5 – 3.5 MPa |
Total installed power | 300 – 800 kW |
Application Field | Specific Uses |
General Furniture | Wardrobe back panels, drawer bottoms, simple bookcases, shoe cabinets |
Interior Decoration | Partition wall panels, ceiling substrates, floor underlayment |
Construction Sites | Temporary formwork, protective boards, simple packaging |
Low-Cost Furniture | Rental apartment furniture, student dormitory furniture, office accessories |
Pallet & Packaging | Single-use or light-load pallets, support boards |
Door Substrates | Interior door core boards (non-load bearing) |
We are China professional factory and supplier of OSB board making machine, MDF/HDF making machine and Flakeboard/Particleboard making machine. Whatever which size, thickness, capacity you want to make, and whatever what kinds of raw materials do you use, our professional team can offer a suitable and good solution for you.
From A to Z, from Raw materials to the final wood based panel, we can offer you all necessary machinery. including: Wood chipper, Strander, Disc chipper, Ring flaker, Rotary drum dryer, Vibrating screener, Glue dosing and applying system, Refiner, Mat frorming line, Continuous pre-press, synchronous Cross-cut saw, Multi-layers Hot press /Continuous single layer hot press, Auto edge trimming machine line，Sanding line，etc.
Claim Your Free OSB Line Layout! Get end-to-end plant design from strand preparation to sanding. Receive 3D factory plan within 30 days.
